Jandy | K1100CKC | Levolor Electronic Water Leveler | 110/220V, 100 ft Sensor and 1 in Valve, Single Body

ԱՊՐԱՆՔԻ ՈՒՂԵՑՈՒՅՑ

The Jandy Levolor K1100CKC is a complete electronic water leveling system for a single body of water. It watches the level, and when evaporation or splash-out drops it below the setpoint, it opens the included valve and refills to the preset level. No garden hose, no remembering, no coming back from vacation to a pool below the skimmer.

The thing that separates Levolor from a mechanical float valve is that there are no moving parts in the sensing. A float valve sticks, corrodes, and eventually either stops filling or never stops filling. Levolor senses the water electronically, so there is nothing to rust or jam. It also compensates for waves, so a windy day or a running spillway does not trigger a false fill.

The lock-out feature is the safety net. A time-out sequence limits how long the valve stays open, which prevents an overfill if a sensor is fouled and, just as usefully, exposes a leak. If the system keeps hitting its time-out, water is going somewhere it should not be, and you find out early instead of after a deck fails.

This is the CKC configuration: a 100 foot sensor cable and a 1 inch valve. The controller ships wired for 220V and is field adjustable to 110V at installation. Three LED indicators show power, sensor, and filling status at a glance. The enclosure is waterproof and rated for mechanical room environments.

Installation does not require cutting the pool. The sensor goes wherever a constant water level can be measured, most commonly a skimmer or a static pipe, and no in-deck canisters or pressurized under-deck fill lines are needed.

Features

• Complete electronic water leveling system for one body of water
• 100 foot sensor cable and 1 inch valve included
• 110V or 220V operation, factory wired 220V and field adjustable
• No moving parts in sensing, nothing to rust, stick, or corrode
• Wave compensation prevents false fill triggers
• Lock-out time-out sequence guards against overfilling and reveals hidden leaks
• Three LED indicators for power, sensor, and filling
• Waterproof enclosure suitable for mechanical rooms
• Installs on new or existing pools with no structural modification
• No in-deck canisters or pressurized under-deck fill lines required
• Works for pools, spas, fountains, ponds, and vanishing edge basins

Specifications

• Brand: Jandy
• Manufacturer part number: K1100CKC
• UPC: 052337029155
• Series: Jandy Pro Series Levolor K-1100
• Bodies of water: one
• Sensor cable length: 100 ft
• Valve size: 1 in
• Valves included: one
• Voltage: 110V or 220V, factory wired 220V
• Indicators: three LEDs for power, sensor, and filling
• Enclosure: waterproof
• Country of manufacture: China
• Application: pools, spas, fountains, ponds, vanishing edge basins

Frequently Asked Questions

What is the difference between the K-1100 and the K-2300?

Number of bodies of water. The K-1100 maintains one. The K-2300 maintains two with separate equipment sets, such as a pool and a spa on their own systems, and includes two sensors and two valves.

What does the CKC suffix mean?

Sensor cable length. CKC is the 100 foot sensor. CKA is the 50 foot version. Measure the run from your controller location to the sensor point before ordering.

Does it come wired for 110V or 220V?

It ships wired 220V from the factory and is field adjustable to 110V during installation.

Will it work on my existing pool?

Yes. No modification to the pool surface or structure is required. The sensor mounts wherever a constant water level can be measured, typically a skimmer or a static pipe.

Will wind and waves cause it to fill at the wrong time?

No. The electronics compensate for wave action, which is one of the main reasons to choose an electronic leveler over a mechanical float.

What happens if a sensor fouls or there is a leak?

The time-out sequence closes the valve after a set duration, so it will not run water indefinitely. Repeated time-outs are a sign of a leak, which is useful information rather than a surprise water bill.

Can I use it on a fountain or a vanishing edge basin?

Yes. It works anywhere a consistent water level is needed, including fountains, ponds, and negative edge basins.

Can I install this myself?

The controller is a hard wired electrical device and the valve ties into your fill line. Installation should be done by a licensed electrician or a qualified pool professional, and local electrical and plumbing code applies.
